Pre-feeder with computer learning function
CPF-05A
The computer learning function ensures smooth wire delivery. The machine also absorbs slack in the wire itself, and its unique straightening device enhances processing precision. Furthermore, the machine has demonstrated high-speed wire feed at a maximum speed of 3.3 m per second, enabling higher-value processing.
Product Specifications
| Model | CPF-05A |
| Body dimensions | Width 420mm x depth 1,135-1,420mm x height 1,350mm |
| weight | 40kg |
| power supply | AC100V or 110V or 220V 50Hz/60Hz (single-phase power supply) |
| Power consumption | 30W when stationary, 130W at maximum rotation (AC100V) |
| External Output | Maximum 5A (AC100V) |
| Wire size | Maximum ⌀6mm *However, this depends on the wire material. |
| Wire rod feed speed | up to 3.3m/sec |
