Automatic wire feeder
CPD-06L
A sensor measures the remaining outer diameter of the wire (bobbin), receives cutting length data from the processing machine, and always feeds the wire at the optimal speed. By operating the accumulation roller horizontally, stress on the wire during length measurement acceleration is absorbed, ensuring smooth wire feeding.
*If purchasing this item alone, a separate set kit is required.
Product Specifications
| Model | CPD-06L |
| Body dimensions | Width 350mm x Depth 400mm x Height 755mm |
| Dimensions including arms | Width 450mm x Depth 545mm x Height 755-1,005mm |
| weight | 35kg |
| power supply | AC200V-240V 50Hz/60Hz (single-phase power supply) |
| Power consumption | 12W at rest, 70W at maximum (AC200V) |
| power | Stepping motor |
| Shaft rotation speed | Max 1,200rpm |
| Applicable wire size | AWG #18 to #40 |
| Bobbin outer diameter | Maximum ⌀600mm* |
| Bobbin Weight | up to 20kg |
| Bobbin width | Maximum 200m |
| Bobbin hole diameter | 20 to 40 mm |
*However, this depends on the wire material.
